dc/dc meniče |
|
táto stránka obsahuje
katalógové listy DC/DC meničov Schmid-M vo formáte
PDF
|
|
|
|
1500 typov
skladom - až 6000Vdc izolácia - ponúkame zákaznícke typy -
pracovná teplota -40°C až +80°C - technická podpora -
najlepší
pomer cena/výkon - vzorky zdarma - RoHs - SMD typy (SAT,
SBT, SET, SFT) - DIL, SIL puzdro |

|
|
Referenčná
tabuľka Traco a Schmid-M DC/DC meniče
skladom viac ako 1000 typov
meničov
Katalóg podľa sérií: |
|
Series |
WATT |
Single/Dual |
Input
Vdc |
Output
Vdc |
Output Current
(mA) |
Features |
SA |
0.25 |
Single |
5,
12, 15 |
5
- 24 |
50
- 11 |
4
Pin SIL //8 DIL Package, Unregulated,
Efficiency up to 82%,
1k / 3k Vdc Insolation,
Non-conductive plastic
case,
MTBF > 2 Mhours |
0.50 |
100
- 21 |
1.00 |
Dual Separate |
5,12,
24 |
5-24,
±5 - ±24 |
100-25,
±100 - ±25 |
Single |
5
– 24 |
200
– 50 |
Dual |
±
5 - ±24 |
±100
- ±25 |
1.50 |
Single |
5,
12, 24 |
5
- 24 |
300
– 62 |
SB |
1.00 |
Single |
4.5~9.9~18,
18~36 |
5
- 24 |
200
– 42 |
8
Pin SIL// 16 Pin DIL
Package, Regulated, Efficiency
up to 78%, 1k/3k Vdc Isolation |
2.00 |
400
- 83 |
SC |
Customer designed series |
SD |
1.50 |
Single/ Dual |
9
~18,18 ~36, 36 ~72 |
5
– 24/ ±5 - ±24 |
300
– 63/ ±150 - ±32 |
24
Pin DIL Package, Regulated,
Efficiency up
to 83%, 1.5k/ 3.5k Vdc Isolation, Nickel-Coated Copper metal, MTBF > 1.5 MHours, Continuous
Short Circuit
Protection, Wide
2:1 Input range |
2.00 |
400
– 84/ ±200 - ±42 |
3.00 |
600
– 125/ ±300 - ±63 |
4.00 |
800
– 167/ ±400 - ±84 |
5.00 |
1000
– 209/±500 - ±105 |
6.00 |
1200
– 250/±600 - ±125 |
SE |
2.00 |
Single |
5,
12, 24 |
5
- 24 |
400
- 83 |
4
Pin SIL Package, Unregulated,
Efficiency up
to 88%, 1k / 3k Vdc Icolation |
SF |
1.50 |
Single |
5,
12, 24 |
5
- 24 |
300
– 63 |
12
Pin DIL Package, Regulated,
Efficiency up
to 72%, 1k/ 3k Vdc isolation, MTFB > 1.5 MHours |
2.00 |
400
– 83 |
3.00 |
600
- 125 |
SG |
1.50 |
Single
/ Dual |
9
~18,18 ~36, 36 ~72 |
5
– 24/ ±5 - ±24 |
300
– 63/ ±150 - ±32 |
24
Pin DIL Package, Regulated,
Efficiency up
to 83%, 1.5k/3k Vdc Isolation, Nickel-coated Copper metal, MTFB > 1.12 MHours, Continuous
Short circuit
protection, Wide
2:1 Input Range |
2.00 |
400
– 84/ ±200 - ±42 |
3.00 |
600
– 125/ ±300 - ±63 |
4.00 |
800
– 167/ ±400 - ±84 |
5.00 |
1000
– 209/ ±500 - ±105 |
6.00 |
1200
– 250/ ±600 - ±125 |
SJ |
1.50 |
Single
/ Dual |
9~18,18~36,36~72 |
3.3–24/ ±3.3-±24 |
400
– 63/ ±200 - ±32 |
24
Pin DIL Package, Regulated,
Efficiency up
to 83%, 1.5k/ 3.5kVdc Isolation, Nickel-Coated copper metal, MTFB>1.05 MHours, Continuous
Short Circuit
Protection, Wide
4:1 Input Range |
2.00 |
9
~ 36, 18 ~ 72 |
600
– 84/ ±300 - ±42 |
3.00 |
900
– 125/ ±600 - ±63
|
4.00 |
1200
– 167/ ±600 - ±84 |
5.00 |
1000
– 209/ ±758 - ±104 |
6.00 |
1200
– 250/±900 - ±125 |
SK |
1.50 |
Single
/ Dual |
9
~ 36, 18 ~ 72 |
3.3–24/ ±3.3-±24 |
400
– 63/ ±200 - ±32 |
24
Pin DIL Package, Regulated,
Efficiency up
to 83%, 1.5k/ 3.5kVdc Isolation, Nickel-Coated copper metal, MTFB>1.05 MHours, Continuous
Short Circuit
Protection, Wide
2:1 Input Range |
2.00 |
600
– 84/ ±300 - ±42 |
3.00 |
900
– 125/ ±600 - ±63
|
4.00 |
1200
– 167/ ±600 - ±84 |
5.00 |
1000
– 209/ ±758-±104 |
6.00 |
1200
– 250/ ±900-±125 |
SQ |
4.00 |
Single
/ Dual |
9
~ 36, 18 ~ 72 |
3.3–24/ ±3.3-±24 |
1200
– 167 / ±600 - ±84 |
24
Pin DIL Package, Regulated,
Efficiency up
to 78%, Wide 4:1 Input Range, 1/ 3kVdc Isolation,
MTFB>1.03 MHours |
5.00 |
1000–209
/ ±758- ±104 |
6.00 |
1200–250
/ ±900- ±125 |
SR |
0.5A output curent |
Single |
4.75~30,
4.75~34, 6.5~34, 8.0~34,… |
1.5~15 |
500 |
3
Pin SIL, Non Isolated, No need
for headsink.
Wide input range, step-down switching |
S1 |
0.50 |
Single
/ Dual |
5,
12, 24 |
5
– 24/ ±5-±24 |
100
– 21/ ±50 - ±11 |
7
Pin SIL // 14 PinDIL Package, Unregulated, Eff.
up to 82%, 1k / 3k/6kVdc isolation, Non conductive Black Plastic Case MTBF>2Mhrs |
0.75 |
150
– 32/ ±75 - ±16 |
1.00 |
200
– 42/ ±100 - ±21
|
1.00 |
Dual Separate |
5,
3.3-5, 15 |
100,
151 – 100, 33 |
2.00 |
5,
5-5, 15 |
100,
100 – 34, 34 |
S2 |
1.00 |
Dual
Split |
5,
12, 15, 24 |
5,
5 |
100,
100 |
7
Pin SIL Package, Regulated,
Efficiency up
to 69%, 1k/3kVdc Isolation |
S3 |
1.00 |
Dual Separate |
5,
12, 24 |
5,
3.3 – 5, 15 |
200,
200 – 200, 67 |
7
Pin SIL // 14 PinDIL Package, Unregulated, Eff.
up to 86%, 1k / 3k/6kVdc isolation, Low Ripple&Noise,
MTBF>2Mhrs |
2.00 |
5,
5 – 15, 15 |
200,
200 – 67, 67 |
2.00 |
Single
/ Dual |
5
– 24/ ±5-±24 |
400
– 83/ ±200 - ±42 |
S4 |
1.00 |
Single |
5,
12, 24 |
5
– 15 |
200
- 67 |
7
Pin SIL // 14Pin DIL
Package, Regulated, Eff. up to 70%, 1k/3kVdc Isolation |
S5 |
1.50 |
Single
/ Dual |
5,
12, 24 |
5
-24/ ±5-±15 |
200,
200 – 200, 67 |
24Pin
DIL Package, Regulated,
Eff. up to
72%,1k/3kVdc isolation |
2.00 |
200,
200 – 67, 67 |
3.00 |
400
– 83/ ±200 - ±42 |
S6 |
1.50 |
Single
/ Dual |
9
~18,18 ~36, 36 ~72 |
5
-24/ ±5-±24 |
300
– 63/ ±150 - ±32 |
24
Pin DIL Package, Regulated,
Efficiency up
to 83%, 1.5k/3.5k Vdc Isolation, Nickel-coated Copper metal, Continuous Short Circuit Protection,
MTFB > 1.1 MHours, Wide 2:1 Input Range |
2.00 |
400
– 84/ ±200 - ±42 |
3.00 |
600
– 125/ ±300 - ±63 |
4.00 |
800
– 167/ ±400 - ±84 |
5.00 |
1000
– 209/ ±500 - ±105 |
6.00 |
1200
– 250/ ±600 - ±125 |
|
|
|
|
|
|
|
|
|
|
